Dishwashers and glasswashers
SMART S60
The SMART line includes a wide range of electronic undercounter glasswashers and dishwashers.
The Smart line appliances are easy to use, have low running costs and are built to be durable.
Dishwasher and glasswasher
Line: Smart Model S60
Basket size: 500 mm
The Smart line appliances are easy to use, have low
running costs and are built to be durable.
Electronic board
Cold rinse activated by a dedicated button
Mechanical rinse aid dispenser
Three different washing cycles available
Guaranteed rinsing temperature
Two crockery baskets
Surface filters
Adjustable peristaltic detergent and rinse aid dispenser
Adjustable peristaltic detergent or rinse aid dispenser
Guaranteed rinse temperature and pressure
Drain pump
Equipment
Optional
Not possible
- 2.800 - 1.000 /h
- 720 - 360 /h
- 3x230 V/400 V + N (50 Hz)
- 500x500 mm
- 430 mm
- mm 705 x 841 x h 1474 - mm 705 x 950 x h 1955 (open)
Electric supply: 3×230/400 V
+ N (50Hz)
Wash pump power: 0.75 kW + 0,75 kW
Boiler element: 6 kW
Tank element: 4.5 kW
Total power rating: 6.75 kW
Boiler capacity: 8 L
Wash tank capacity: 60 L
Rinse temperature: 82 °C
Wash temperature: 60 °C
Cycle time: 90/180″
Required water pressure: 2-4 bar
∅ Water supply hose/drain hose: 3/4″ gas / 25 mm
Supply water temperature: Max 50 °C
Noise emission: <75 dBA
Net weight: 108 kg
